INPUT SPECIFICATIONS:

• INPUT Connectors:INPUT(1,2)

• INPUT Impedance:15ohm

• Source Impedance:600 ohm Lines

• Sensitivity:+4dB(1.23V)

• Nominal Level:+4dB(1.23V)

• Maximum Before Clipping:+21dB(11.2V)

• Connectors:XLR-3-31 Type

OUTPUT SPECIFICATIONS:

• OUTPUT Connectors:OUTPUT(1,2)

• OUTPUT Impedance:150ohm

• Load Impedance:600ohm Lines

• Nominal Level:+4dB(1.23V)

• Maximum Before Clipping:21dB(11.2V)

• Connectors:XLR-3-32 Type

• Frequency Response:20Hz-20KHz ± 0.5dB @ +4dB *600 ohm

• Total harmonic Distortion:Less than 0.05 (20Hz-20KHz@+4dB 600ohm)

• Hum & Noise:-90dB

• Maximum Voltage Gain:0dB, Input Level...Max.

• EQUALIZER CONTROLS Center Frequencies:31 band (1/3 octave)

• Variable Range:± 12dB

• HIGH PASS FILTER (Roll off Frequency):12dB/octave (50Hz at -3dB point)

• Power Consumption:20W

• Dimensions(HXLXD) :482x88x130mm

• Weight:2.75kg
