Smarter Unit:

Based on Pulse Width Modulation (PWM) technology which has been used for over 30 years in power supply and converter, adopt complete digital circuit PWM for high reliability, smaller sizes, less weight

Higher Efficiency:

Its efficiency is nearly independent from output level while other common amplifiers can get max efficiency only at biggest output. The overall electric energy convert efficiency is more than 80%.

More Accurate Sound:

Crystal clear high frequency, tight and strong low frequency, accurate sound reproduction, professional design ensure great specifications such as distortion, frequency response, convert rate, power supply band width and damping factor. This TC series amplifier adopts higher frequency convert to obtain high resolution of sound signal.

More Comprehensive Protection:

This Series amplifier can prevent from and correct every possible fault, can supply powerful output, safely working and long time reliability.

Output Power(8Ω):8Ω/1KHz:2×450w

Output Power(4Ω):4Ω/1KHz:2×800w

Output Power(2Ω):2Ω/1KHz:2×1400w

RMS Output Voltage (THD=1%,1kHz):60V

16 ohm Bridged Output Power:1×900w

8 ohm Bridged Output Power:1×1600w

4 ohm Bridged Output Power:1×2800w

weight:8KG

Upward Slope(1kHz,LP Filter):50V/us

Input Sensitivity(Rated Power,1kHz):1Vrms

THD(10%Rated Output Power,Typical):0.05%

Measurable IMD(10%Rated Output Power,Typical):0.05%

IMD(10%Rated Output Power,Typical):0.05%

Crosstalk(1kHz,Typical):-70dB

Frequency Response(10%Rated Output Power)8Ω: 0～-2dB

Input Impedance(Balanced):Balanced 20KΩ,Unbalanced 10KΩ

Damping Factor(100Hz,8Ω):≥200

S/N(A Weight,20Hz-20kHz):≥105dB

Power Supply:AC～100-240V(50-60Hz)

Protection:Overheat Protection、Temperature Power Control、Output Current Control Overload Protection、DC output Protection

Dimension (mm):483×370×44
